Portable Pipe Beveler with Cold Cutting for 3.15"-10.75" Weld Preparation
| MOQ: | 1 |
| Price: | 370USD-1110USD |
| Delivery Period: | 5-7 days |
| Payment Method: | T/T |
Detail Information
Place of Origin
Wuxi, China
Brand Name
MT Portable Machine
Certification
ISO9001 & CE
Model Number
ID252
Cutting Range (ID-OD):
Φ80–273 Mm (3.15"–10.75")
ID Mounting Range:
Φ80–260 Mm (3.15"–10.24")
Wall Thickness:
≤20 Mm (0.79")
Feed Stroke:
26 Mm (1.02")
Highlight:
portable ID mounted pipe beveler
,cold cutting weld preparation tool
,pipe beveler 3.15-10.75 working range
Product Description
Portable ID Mounted Cold Cutting Weld Preparation Tool 3.15"-10.75" Working Range
Pipe Beveler ID252 - Portable ID Mounted Cold Cutting Weld Preparation Tool
The ID252 Pipe Beveler is a compact and high-efficiency internal diameter mounted pipe beveling machine, engineered for precise weld end preparation on pipes and tubes ranging from 3.15" to 10.75" (Ø80-273 mm). Designed for both workshop fabrication and on-site operations, it is widely applied in power generation, petrochemical plants, refinery maintenance, and pipeline construction.
Utilizing a true cold cutting process, the ID252 delivers clean and accurate bevels without generating heat, eliminating the risk of metallurgical changes or deformation. The machine is capable of processing carbon steel, stainless steel, and high-alloy materials, ensuring consistent results even in demanding applications.
With interchangeable tooling, the ID252 supports beveling, facing, counterboring, and J-prep operations. Available with electric or pneumatic drive options, it offers excellent flexibility for different working conditions, including hazardous or explosion-sensitive environments.
Key Features
- Cold Cutting for Superior Weld Quality: The ID252 performs a fully mechanical cold cutting process, preventing heat-affected zones and preserving the original material properties for optimal weld integrity.
- Wide Material Compatibility: Suitable for machining carbon steel, stainless steel, duplex steel, and various alloy steels commonly used in industrial piping systems.
- Multi-Operation Capability: By changing tool bits, the machine can efficiently carry out V-bevels, U-bevels, facing, counterboring, chamfering, and J-prep in a single setup.
- Quick Internal Clamping System: A self-centering three-jaw expanding mandrel ensures fast installation, strong internal grip, and excellent concentricity during machining.
- Adjustable Bevel Angles: Standard bevel angles from 0° to 45° are supported, with customized cutting tools available for special weld preparation requirements.
Specifications
| Item | IDE-252 | IDP-252 |
|---|---|---|
| Drive Type | MT electric motor | Pneumatic motor |
| Motor Power | 220-240 V, 50/60 Hz | 1.3 m³/min @ 0.6 Mpa |
| Motor Power | 1.6 Kw (2.15 Hp) / 6 A | 1.0 Kw (1.34 Hp) |
| Cutting Range (ID-OD) | Φ80-273 mm (3.15"-10.75") | Φ80-273 mm (3.15"-10.75") |
| ID Mounting Range | Φ80-260 mm (3.15"-10.24") | Φ80-260 mm (3.15"-10.24") |
| Wall Thickness | ≤20 mm (0.79") | ≤20 mm (0.79") |
| Feed Stroke | 26 mm (1.02") | 26 mm (1.02") |
| Rotation Speed | 22 rpm | 44 rpm |
| Working Weight | 33 Kg | 30 Kg |
| Shipping Weight | 52 Kg | 50.5 Kg |
| Crate Dimensions | 820×370×330 mm | 720×370×330 mm |
Drive Options
IDE252 - Electric Drive Version
Powered by a 1.6 kW MT electric motor, the IDE252 delivers stable torque and smooth cutting performance. Operating on 220-240 V, 50/60 Hz, it is ideal for fabrication shops, maintenance workshops, and industrial plants where consistent power supply is available. This version is well suited for continuous-duty operation, high-precision beveling, and reduced operator effort.
IDP252 - Pneumatic Drive Version
The IDP252 features a 1.0 kW pneumatic motor, running on 1.3 m³/min of compressed air at 0.6 MPa. The air-driven system is inherently explosion-proof, making it a safe choice for oil & gas, chemical, and offshore environments. Its lightweight structure and high rotational speed ensure efficient on-site pipe beveling where electrical power is limited or prohibited.
Standard Accessories
| No. | Description | Qt |
|---|---|---|
| 1 | Modle ID252 assembly with motor | 1 |
| 2 | Jaw block No.1 (Φ100-120 mm,L=10 mm) | 6 |
| 3 | Jaw block No.2 (Φ120-140 mm,L=20 mm) | 6 |
| 4 | Jaw block No.3 (Φ140-160 mm,L=30 mm) | 6 |
| 5 | Jaw block No.4 (Φ160-180 mm,L=40 mm) | 6 |
| 6 | Jaw block No.5 (Φ180-200 mm,L=50 mm) | 6 |
| 7 | Jaw block No.6 (Φ200-220 mm,L=60 mm) | 6 |
| 8 | Jaw block No.7 (Φ220-240 mm,L=70 mm) | 6 |
| 9 | Jaw block No.8 (Φ240-260 mm,L=80 mm) | 6 |
| 10 | 42F-0822-0°,M42 Facing tool, 8×22 mm, 0° | 1 |
| 11 | 42B-0822-30°,M42 Beveling tool, 8×22 mm, 30° | 1 |
| 12 | 42B-0822-37.5°,M42 Beveling tool, 8×22 mm, 37.5° | 1 |
| 13 | Hex L-key 5 mm | 1 |
| 14 | Hex L-key 6 mm | 1 |
| 15 | Hex L-key 8 mm | 1 |
| 16 | Hex L-key 10 mm | 1 |
| 17 | Combination open end wrench, 22-24 mm | 1 |
| 18 | Eyebolt M10 | 1 |
| 19 | Manual and certificates | 1 |
Mounting Range
| Jaw Blocks and Ramp Sets | ID Mounting Range |
|---|---|
| None | Φ80-100 mm (3.150"-3.937") |
| NO.01 | Φ100-120 mm (3.937"-4.724") |
| NO.02 | Φ120-140 mm (4.724"-5.512") |
| NO.03 | Φ140-160 mm (5.512"-6.299") |
| NO.04 | Φ160-180 mm (6.299"-7.087") |
| NO.05 | Φ180-200 mm (7.087"-7.874") |
| NO.06 | Φ200-220 mm (7.874"-8.661") |
| NO.07 | Φ220-240 mm (8.661"-9.449") |
| NO.08 | Φ240-260 mm (9.449"-10.236") |
Toolbit Options
Pipe Beveler Selection Table
| Model | ID Mounting Range | Cutting Range (ID-OD) |
|---|---|---|
| ID30 | Φ15-28 mm (0.59"-1.10") | Φ15-36 mm (0.59"-1.42") |
| ID90 | Φ25-79 mm (0.98"-3.11") | Φ25-89 mm (0.98"-3.50") |
| ID120 | Φ40-112 mm (1.57"-4.41") | Φ40-120 mm (1.57"-4.72") |
| ID159 | Φ60-160 mm (2.36"-6.30") | Φ60-159 mm (2.36"-6.26") |
| ID219 | Φ65-215 mm (2.56"-8.46") | Φ65-219 mm (2.56"-8.62") |
| ID252 | Φ80-260 mm (3.15"-10.24") | Φ80-273 mm (3.15"-10.75") |
| ID352 | Φ145-345 mm (5.71"-13.58") | Φ145-356 mm (5.71"-14.02") |
| ID426 | Φ250-426 mm (9.84"-16.77") | Φ250-426 mm (9.84"-16.77") |
| ID630 | Φ300-630 mm (11.81"-24.80") | Φ300-630 mm (11.81"-24.80") |
